TECHNICAL CHARACTERISTICS
|
| Bus type |
Tourist bus |
| Body type |
All-metal, wagon type |
| Chassis |
FAW CA 6102D92-1 |
| Passenger capacity |
|
| total places |
43+1 service |
| sitting places |
43+1 service |
| Dimensions, mm |
|
| length |
10280 |
| width |
2480 |
| height |
3200 |
| Wheel base, mm |
5000 |
| Wheel track, mm |
|
| front wheels |
1900 |
| back wheels |
1836 |
| Equiped bus weight, kg |
9900 |
| Total design weight, kg |
13200 |
| Engine |
|
| model, type |
FAW CA6DE2 18,, 4-cycle, turbocharged |
| number and positioning of cylinders |
6, rows |
| feed system |
with forced fuel supply |
| maximum capacity, kWt(h.p.) |
132 (179.5) |
| maximum rotational moment, Nm |
680,0 |
| cooling system |
fluidal |
| Fuel consumption, l/100km |
|
| at 60 km/h |
24,0 |
| in city cycle |
33,0 |
| Gear box |
mechanical, 6-stepped, synchronize on all transmissions of forward running |
| Suspension |
|
| front |
dependent, spring with telescopic shock absorbers of 2-sides action |
| back |
dependent, spring with telescopic shock absorbers of 2-sides action |
| Steering control |
integral type |
| Brake system |
|
| working |
pneumatic, double-loop with ABC |
| reserve |
combined with one of loops of working brake system |
| parking |
with a drive to brake mechnisms of rear wheels from spring brake |
| Doors |
|
| passenger |
single-door with pneumatic drive |
| reserve |
single-door with pneumatic drive |
| Luggage space volume, sq. m |
1,69 |
| Tyres |
9,00 - 20 |
| Heating system |
autonomous fluid heater of stream type with compartment heaters of convection type, connected with a bus engine cooling system
|
| Maximum speed, km/h |
100 |
|
