TECHNICAL CHARACTERISTICS
|
| Bus type |
Intercity bus
|
| Body type |
All-metal, wagon type |
| Chassis |
FAW CA 6102D921 |
| Passenger capacity |
|
|
total places
|
60 |
| sitting places
|
43
|
| Dimensions, mm |
|
| length
|
10280 |
| width
|
2480 |
| height
|
2980 |
| Wheel base, mm |
5000 |
| Wheel track, mm |
|
| front wheels
|
1900 |
| back wheels
|
1836 |
| Equiped bus weight, kg |
9400 |
| Total design weight, kg |
14000 |
| Engine |
|
| model, type
|
FAW CA6DE2 18, 4-cycle, turbocharged
|
| number and positioning of cylinders
|
6, rows
|
| feed system
|
with forced fuel supply
|
| maximum capacity, kWt(h.p.)
|
132 (179.5) |
| maximum rotational moment, Nm
|
680,0 |
| cooling system
|
fluidal
|
| Fuel consumption, l/100km |
|
| at 60 km/h
|
24,0 |
| in city cycle
|
33,0 |
| Gear box |
mechanical, 6-stepped, synchronize on all transmissions of forward running |
| Suspension |
|
| front
|
dependent, spring with telescopic shock absorbers of 2-sides action and a stabilizer of transverse stability
|
| back
|
dependent, spring with telescopic shock absorbers of 2-sides action |
| Steering control |
integral type |
| Brake system |
|
| working
|
pneumatic, double-loop with ABC |
| reserve
|
combined with one of loops of working brake system |
| parking
|
with a drive to brake mechnisms of rear wheels from spring brake |
| Doors |
|
| passenger |
single-door with pneumatic drive |
| reserve |
single-door with pneumatic drive |
| Luggage space volume, sq. m |
1,69 |
| Tyres |
9,00 - 20 |
| Heating system |
autonomous fluid heater of stream type with compartment heaters of convection type, connected with a bus engine cooling system
|
| Maximum speed, km/h |
100 |
|
