TECHNICAL CHARACTERISTICS
|
| Bus type |
City bus |
| Body type |
Frame |
| Passenger capacity |
|
| total places |
41 |
| sitting places |
19+1+1 |
| Dimensions, mm |
|
| length |
7190 |
| width |
2240 |
| height |
2840 |
| Wheel base, mm |
|
| front wheels |
1810 |
| back wheels |
1610 |
| Equiped bus weight, kg |
4600 |
| Total design weight, kg |
7500 |
| Maximum axial load, kg |
|
| front axle |
3000 |
| back axle |
4500 |
| Engine |
|
| model, type |
FAW CA4D3212 diesel, turbocharged, EURO ІІ |
| number and positioning of cylinders |
4, rows |
| working volume, liters |
3,168 |
| maximum capacity, kWt(h.p.) |
88 (119) |
| maximum rotational moment, Nm |
300 |
| cooling system |
fluidal |
| Fuel consumption, l/100km |
|
| at 60 km/h |
16,0 |
| at 80 km/h |
16,5 |
| Gear box |
mechanical, 5-stepped |
| Suspension |
|
| front |
dependent on 2 semi-elliptical springs with telescopic hydraulic shock absorbers and a stabilizer of transverse stability |
| back |
dependent on 2 semi-elliptical springs with telescopic hydraulic shock absorbers |
| Steering control |
with hydraulic booster |
| Brake system |
|
| working |
pneumatic, double-loop with a corrector of braking-forces in driving gear |
| parking |
with spring brake |
| Doors |
two passenger doors with air-powered drive, located before front and after back wheels |
| Tyres |
radial 215/75 R17,5 |
| Maximum speed, km/h |
90 |
|
