TECHNICAL CHARACTERISTICS
|
| Bus type |
City bus |
| Body type |
With intergrated chassis |
| Chassis |
FAW CA 6102D92-1 |
| Passenger capacity |
|
| total places |
up to 79 |
| sitting places |
from 23 to 44 |
| Dimensions, mm |
|
| length |
10280 |
| width |
2480 |
| height |
2980 |
| Wheel base, mm |
5000 |
| Wheel track, mm |
|
| front wheels |
1900 |
| back wheels |
1836 |
| Total design weight, kg |
14560 |
| Engine |
|
| model, type |
diesel FW CA6DE2-18 |
| number and positioning of cylinders |
6, rows |
| maximum power, kWt(h.p.) |
132 (179,5) |
| maximum rotational moment, Nm |
680 |
| cooling system |
fluidal |
| Fuel consumption, l/100km |
|
| at 60 km/h |
24,0 |
| Gear box |
mechanical, 6-stepped |
| Suspension |
|
| front |
dependent, spring with telescopic shock absorbers of 2-sides action and a stabilizer of transverse stability |
| back |
dependent, spring with telescopic shock absorbers of 2-sides action and a stabilizer of transverse stability |
| Steering control |
with hydraulic amplifier |
| Brake system |
hydraulic, double-loop with vacuum amplifier |
| working |
pneumatic, double-loop with ABC |
| parking |
with spring brakes |
| Tyres |
9,00 - 20 |
| Heating system |
autonomous fluid heater of stream type with compartment heaters of convection type, connected with a bus engine cooling system
|
| Maximum speed, km/h |
100 |
|
