TECHNICAL CHARACTERISTICS
|
| Bus type |
Minibus (fixed-run taxi type) |
| Body type |
Frame |
| Passenger capacity |
|
| 3-rows compartment projection: |
|
| total places |
18 |
| sitting places |
14 |
| Dimensions, mm |
|
| length |
5680 |
| width |
2070 |
| height |
2630 |
| Wheel base, mm |
3150 |
| Wheel track, mm |
|
| front wheels |
1710 |
| back wheels |
1570 |
| Equiped bus weight, kg |
2620 |
| Total design weight, kg |
3980 |
| Maximum axial load, kg |
|
| front axle |
1400 |
| back axle |
2580 |
| Engine |
|
| model, type |
ZMZ 40522 |
| number and positioning of cylinders |
4, rows |
| working volume, liters |
2,464 |
| maximum capacity, kWt(h.p.) |
106,6 (145) |
| maximum rotational moment, Nm |
20,79 |
| cooling system |
fluidal |
| Fuel consumption, l/100km |
|
| at 60 km/h |
10,0 |
| in city cycle |
12,0 |
| Gear box |
5-stepped |
| Suspension |
|
| front |
dependent on 2 semi-elliptical springs with telescopic shock absorbers of 2-sides action and a stabilizer of transverse stability |
| back |
ependent on 2 semi-elliptical springs amd additional springs with and a stabilizer of transverse stability |
| Steering control |
of type screw-nut-rack-sector |
| Brake system |
|
| working |
hydraulic, double-loop with vacuum booster |
| reserve |
combined with one of brake system loops |
| parking |
with mechanical drive to brake blocks |
| Doors |
|
| passenger |
with pneumatic drive |
| reserve |
with manual opening |
| Tyres |
radial 175 R16C, 185 R16C |
| Maximum speed, km/h |
not less than 90 |
|
