TECHNICAL CHARACTERISTICS
|
Bus type |
Tourist bus |
Body type |
Frame with forward engine location |
Chassis |
ТАТА LP 613/38 BUS |
Passenger capacity |
|
3-rows compartment projection |
23 |
4-rows compartment projection |
28 |
Dimensions, mm |
|
length |
8120 |
width |
2260 |
height |
2888 |
Wheel base, mm |
4550 |
Wheel track, mm |
|
front wheels |
1660 |
back wheels |
1577 |
Equiped bus weight, kg |
5540 |
Total design weight, kg |
7730 |
Engine |
|
model, type |
diesel, ТАТА 697 TC55L EURO II |
number and positioning of cylinders |
6, rows |
working volume, l |
5,675 |
maximum capacity, kWt(h.p.) |
101,5 (138) |
maximum rotational moment, Nm |
416 |
cooling system |
fluidal |
Fuel consumption, l/100km |
|
at 60 km/h |
15,0 |
at 80 km/h |
22,0 |
Gear box |
mechanical, 5-stepped |
Suspension |
|
front |
dependent on 2 semi-elliptical springs with telescopic shock absorbers of 2-sides action and a stabilizer of transverse stability |
back |
dependent on 2 semi-elliptical springs with and a stabilizer of transverse stability |
Steering control |
with hydraulic booster |
Brake system |
|
working |
pneumatic, double-loop with ABC |
parking |
with spring brake |
Doors |
|
passenger |
single-door with manual opening |
reserve |
single-door with manual opening |
Luggage space volume, sq. m |
1,78 |
Tyres |
215/75 R17,5 |
Heating system |
autonomous from fluid heater Webasto |
Maximum speed, km/h |
90 |
|
